AOTF380A60CL High Voltage MOSFETs (500V - 1000V)
Alpha and Omega Semiconductor
AOTF380A60CL ：600V, aMOS5™ N-Channel Power Transistor
N-Channel 600 V 11A (Tj) 27W (Tc) Through Hole TO-220F
| Part Number | Mounting Type | FET Type | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Drive Voltage (Max Rds On, Min Rds On) | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Vgs (Max) | Power Dissipation (Max) | Operating Temperature | Input Capacitance (Ciss) (Max) @ Vds | Package Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| AOTF380A60CL | Through Hole | N-Channel | 600 V | 11A (Tj) | 10V | 3.8V @ 250µA | 20 nC @ 10 V | ±20V | 27W (Tc) | -55°C ~ 150°C (TJ) | 955 pF @ 100 V | TO-220-3 Full Pack |
-
Datasheet Download on Sep, 2020
