AOTF380A60CL High Voltage MOSFETs (500V - 1000V)

Alpha and Omega Semiconductor

AOTF380A60CL ：600V, aMOS5™ N-Channel Power Transistor

N-Channel 600 V 11A (Tj) 27W (Tc) Through Hole TO-220F

Product Number: AOTF380A60CL

Class: Discrete Semiconductor Products,Transistors IGBTs, Single IGBTs

Tag: IGBTs, Single IGBTs

Proprietary aMOS5™ technology
Low RDS(ON)
Optimized switching parameters for better EMI performance
Enhanced body diode for robustness and fast reverse recovery

Applications ：
SMPS with PFC, Flyback and LLC topologies
Silver ATX ,adapter, TV, lighting, Server power

Part Number Mounting Type FET Type Drain to Source Voltage (Vdss) Current - Continuous Drain (Id) @ 25°C Drive Voltage (Max Rds On, Min Rds On) Vgs(th) (Max) @ Id Gate Charge (Qg) (Max) @ Vgs Vgs (Max) Power Dissipation (Max) Operating Temperature Input Capacitance (Ciss) (Max) @ Vds Package Type
AOTF380A60CL Through Hole N-Channel 600 V 11A (Tj) 10V 3.8V @ 250µA 20 nC @ 10 V ±20V 27W (Tc) -55°C ~ 150°C (TJ) 955 pF @ 100 V TO-220-3 Full Pack

See more...AOS

  • See below for downloadable documentation, software, and other resources.

    Datasheet Download on Sep, 2020
